MikroTik GPOE-CON-mini PoE Converter
MikroTik GPOE-CON-mini converts 48–57 V 802.3af/at PoE to 24 V passive PoE for compatible devices, with two 2.5G Ethernet ports in a compact enclosure.
MikroTik
MikroTik provides hardware and software for Internet connectivity. Our experience in using industry standard PC hardware and complete routing systems allowed us in 1997 to create the RouterOS software system that provides extensive stability, controls, and flexibility for all kinds of data interfaces and routing.
Share this product:
MikroTik GPOE-CON-mini 24 V Passive PoE Converter
Product code: GPOE-CON-mini
The MikroTik GPOE-CON-mini connects compatible 24 V passive PoE equipment to standard 48–57 V 802.3af/at PoE infrastructure. Its compact housing and two 2.5G Ethernet ports make it a practical inline converter when the available PoE supply does not match the device.
Keep your existing PoE switch and bring power and data to a compatible endpoint without adding a separate injector or power cable.
Key features
48–57 V PoE input
Connect to standard 802.3af/at PoE infrastructure and convert power for a compatible 24 V passive PoE device.
24 V passive PoE output
Bridge the power-standard mismatch without replacing the upstream switch. Check the connected device’s voltage and power requirements.
Two 2.5G ports
Support Ethernet connections up to 2.5 Gbit/s through the converter.
Compact installation
The 87 × 33 × 20 mm enclosure fits tight spaces and the separately sold GPeR IP67 Case.
Ideal applications
- Connecting compatible 24 V passive PoE endpoints to 802.3af/at switches.
- Compact inline power conversion in network cabinets and equipment installations.
- Powering compatible MikroTik LHG, SXTsq, Groove or NetBox ax variants, subject to their exact power requirements.
- Protected outdoor installations using a suitable enclosure such as the separately sold GPeR IP67 Case.
Key specifications
- Product code: GPOE-CON-mini
- Ethernet: 2 × 2.5G Ethernet ports
- DC inputs: 1, via PoE-IN
- PoE input standard: 802.3af/at
- Input voltage: 48–57 V
- Output voltage: 24 V
- PoE output: Passive PoE
- High-voltage PoE-out current limit: 0.635 A
- Maximum total output current: 0.635 A
- Dimensions: 87 × 33 × 20 mm
- Tested ambient temperature: −40 °C to +70 °C
- MTBF: Approximately 100,000 hours at 25 °C
- Certifications: CE, EAC, RoHS
- Included: K-96 fastening set
- Optional enclosure: Compatible with GPeR IP67 Case, sold separately
Why choose the GPOE-CON-mini?
Use existing standards-based PoE infrastructure with compatible 24 V passive PoE equipment. The converter combines a small footprint, 2.5G Ethernet connectivity and straightforward inline installation, helping avoid unnecessary changes to the upstream network.
Frequently asked questions
What does the GPOE-CON-mini convert?
It accepts 48–57 V 802.3af/at PoE and supplies 24 V passive PoE for a compatible connected device.
Does it support 2.5G Ethernet?
Yes. The converter has two 2.5G Ethernet ports and supports connections up to 2.5 Gbit/s.
Which devices can it power?
Use it with devices that support 24 V passive PoE and whose power requirements match the converter. Compatible variants of MikroTik LHG, SXTsq, Groove and NetBox ax are examples; check the exact device specifications before connection.
Is the converter itself IP67-rated?
No IP67 rating is specified for the converter itself. It fits the separately sold GPeR IP67 Case for installations that require a protective enclosure.
What is included?
The GPOE-CON-mini converter and K-96 fastening set are included. The GPeR IP67 Case is not included.
